ImmunoSpot® Analyzers

Wide range of analysis solutions for different needs
and budgets

In 1995, CTL’s founding scientists introduced image analysis-based ELISPOT counting (US Patent 6,410,252 B1), marking the beginning of ImmunoSpot® Analyzers. Since then, thousands of these instruments have been sold world-wide serving the "who's who" of academic and biotechnology researchers. Learn more about why ImmunoSpot® Analyzers have been so successful.

ImmunoSpot® Analyzers are not only the most successful ELISPOT/FluoroSpot analyzers on the market, they also are multifunctional, enabling other tests that are frequently performed in immune monitoring laboratories such as PBMC counting, cytotoxicity and serum neutralization assays, reading cytokine arrays, and more. ImmunoSpot® Analyzers are several instruments in one, for the price of one.

CTL offers a wide range of ImmunoSpot® Analyzers that are tailored to different needs and budgets. Please see our new model lines below. We are happy to help you select the model that suits you best. We also offer factory refurbished analyzers and analysis services.

& Specifications
S6 Lite M2
Learn more
S6 Entry M2
Learn more
S6 Macro M2
Learn more
S6 Micro M2
Learn more
Distinguishing Features
Optical Zoom Capability
Well Formats 96 96, 384 6, 12, 24, 48, 96 (upgradable to all Petri dish formats) 24, 48, 96, 384, 1536 Terasaki (upgradeable to rapid 6/Petri)
Top / Bottom Light / / / /
High-througput (Stacker/Robot compatibility)
Integrated Barcode Reader (upgradeable)
ELISPOT Applications
Single color ELISPOT
Double color ELISPOT
Non-ELISPOT Immunological Applications
Nucleic Acid and Protein Quantification
Histology Slide Analysis Capability
Microscopic Imaging
Visible Light Array Analysis
Advanced Features
BSL 3/4 Suitability
Space Saving Design
Max Image Resolution / Well (megapixels) 1.2 5 10 25
Regulatory Compliance Tiered Solutions Tiered Solutions Tiered Solutions
Software Suites
ImmunoSpot® Single-Color ELISPOT Enzymatic Renewable Software License
ImmunoSpot® Double-Color ELISPOT Enzymatic (upgradeable)
SpotMap™ (upgradeable)
Image Annotator (upgradeable)
SpotStat™ (upgradeable)
ImmunoQualify™ (upgradeable) (upgradeable) (upgradeable)
ImmunoCompliance™ Suite (upgradeable) (upgradeable) (upgradeable)
& Specifications
S6 FluoroCore M2
Learn more
S6 Ultra M2
Learn more
S6 Flex M2
Learn more
S6 Universal M2
Learn more
S6 Ultimate M2
Learn more
Distinguishing Features
No of Fluorescent Channels One Three Four Five (upgradable to 12) Twelve
Modular Design
Optics Fixed Lens Fixed Lens Fixed Lens Motorized Optical Zoom Motorized Optical Zoom
Max Image Resoluton/Well (Megapixels) 10 10 10 25 25
Well Formats 96, 384 24, 48, 96, 384, 1536 and Terasaki (upgradable to rapid 6/Petri) 24, 48, 96, 384, 1536 and Terasaki (upgradable to rapid 6/Petri) 6, 12, 24, 48, 96, 384, 1536 and Terasaki (upgradable to rapid 6/Petri) 6, 12, 24, 48, 96, 384, 1536 and Terasaki (upgradable to rapid 6/Petri)
Microscopic Cell Analysis
PBMC/Cell Counting Live Cell Live and Dead Live and Dead Live, Dead & Apoptotic Live, Dead & Apoptotic
Cell-Mediated Cytotoxicity Assays
Single color ELISPOT
Double color ELISPOT
FluoroSpot Single Color Three Color Four Color Five (upgradable to 12) Twelve Color (Included)
BioSpot Single Color Three Color Four Color Five (upgradable to 12) Twelve Color (Included)
ELISA / Protein / Nucleic Acid quantification upgrade
Core Facility Suitability
Additional Features
Top / Bottom Light
Integrated Barcode Reader
Plate Loader Ready
BSL 3/4 Suitable
Space Saving Design
Suited for Regulatory Compliance
ImmunoSpot® Single-Color ELISPOT Enzymatic
ImmunoSpot® Double-Color ELISPOT Enzymatic
Fluoro-X™ FluoroSpot
Image Annotator
LDA Cell Counting Suite
TVA Cytotoxicity Suite
ODense™ upgrade
SpotStat™ upgrade
SpotMap™ upgrade
ReagentTracker™ upgrade upgrade upgrade upgrade
ImmunoQualify™ upgrade upgrade upgrade upgrade
ImmunoCompliance™ Suite upgrade upgrade upgrade upgrade upgrade
